Sauder 420824 Instructions D'assemblage

Sauder 420824 Instructions D'assemblage

Masquer les pouces

Publicité

Liens rapides

Télécharger ce manuel
CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 8:30 a.m. to 5 p.m. EST (except holidays)
4-Drawer Chest
Harvey Park Collection | Model 420824
Scan to rate and review
your piece at Sauder.com
Your opinion matters!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-523-3987
.
The dresser's
not-so-distant cousin.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 908000
Purchased: __________________
03/14/24

Publicité

loading

Manuels Connexes pour Sauder 420824

Sommaire des Matières pour Sauder 420824

  • Page 1 The dresser's not-so-distant cousin. 4-Drawer Chest NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Harvey Park Collection | Model 420824 PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-28 Français pg 29-32 Scan to rate and review Español pg 33-36 your piece at Sauder.com...
  • Page 2 No. 2 Phillips Screwdriver Hardware Identification Tip Shown Actual Size Hardware Usage Guide Assembly Steps 5-28 Hammer Not actual size Français 29-32 Español 33-36 Pencil Safety 37-38 Electric drill with 1/8" or 3/8" bit (ONLY in indicated step) Warranty Page 2 www.sauder.com/service 420824...
  • Page 3 LEFT DRAWER SIDE (4) LEFT END (1) SKIRT (1) D635 -1 with label RIGHT END (1) BRACE (1) RIGHT DRAWER SIDE (4) D636 -1 with logo TOP (1) BOTTOM (1) D985 DRAWER BOTTOM (4) BALLAST (1) D636 D985 D635 420824 www.sauder.com/service Page 3...
  • Page 4 BLACK 9/16" LARGE HEAD SCREW - 4 3S GOLD 5/16" FLAT HEAD SCREW - 32 BLACK 1-1/4" FLAT HEAD SCREW - 12 10S SILVER 1-1/8" FLAT HEAD SCREW - 3 30S BLACK 1-9/16" FLAT HEAD SCREW - 20 Page 4 www.sauder.com/service 420824...
  • Page 5 Hardware Usage Guide Look for this icon. It means a video assembly tip is available at www.sauder.com/service/tips Find the numbered video or scan the QR code. HOW TO USE A HIDDEN CAM & CAM DOWEL Insert the metal end of the CAM DOWEL into the HIDDEN CAM.
  • Page 6 END (J). Use eight GOLD 5/16" FLAT HEAD Remember: SCREWS (3S) through holes #1 and #3. Righty tighty. Lefty loosey. GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Edge with CAM DOWELS Roller end Page 6 www.sauder.com/service 420824...
  • Page 7 NOTE: Position the SAFETY STRAP exactly as shown. The DRYWALL ANCHOR and LONG SCREW will be used later. Safety Strap x 1 Drywall Anchor x 1 Long Screw x 1 Short Screw x 1 SAFETY STRAP SHORT SCREW 420824 www.sauder.com/service Page 7...
  • Page 8 Fasten the LEFT END (J) to the TOP (L). Tighten two Caution HIDDEN CAMS. Do not stand the unit upright without the BACK fastened. The unit may collapse. i t h f a c S u r D E N H I D SAFETY STRAP Page 8 www.sauder.com/service 420824...
  • Page 9 Push two HIDDEN CAMS (1F) into the BRACE (O). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow Metal end Arrow Metal end 420824 www.sauder.com/service Page 9...
  • Page 10 Fasten the BRACE (O) to the LEFT END (J). Tighten one HIDDEN CAM. å NOTE: Be sure the METAL PIN in the END inserts into the BRACE. S u r f a c i t h H I D D E N Page 10 www.sauder.com/service 420824...
  • Page 11 Push four HIDDEN CAMS (1F) into the BOTTOM (P). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow Metal end Arrow Metal end 420824 www.sauder.com/service Page 11...
  • Page 12 Step 8 å Fasten the BOTTOM (P) to the LEFT END (J). Tighten two HIDDEN CAMS. S u r f a c i t h H I D D E N The small holes must be here. Page 12 www.sauder.com/service 420824...
  • Page 13 Fasten two METAL BRACKETS (4G) to the SKIRT (N). Use two BLACK 9/16" LARGE HEAD SCREWS (1S). å NOTE: Be sure the BRACKETS are even with the short edges of the SKIRT. BLACK 9/16" LARGE HEAD SCREW (2 used in this step) 420824 www.sauder.com/service Page 13...
  • Page 14 BLACK 1-7/8" FLAT HEAD SCREWS (2S). å NOTE: You should start each SCREW a few turns before completely tightening any of them. BLACK 1-7/8" FLAT HEAD SCREW (3 used in this step) Surface with METAL BRACKETS Page 14 www.sauder.com/service 420824...
  • Page 15 Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. å Insert one METAL PIN (1R) into the exact hole shown in the RIGHT END (K). Do not tighten the HIDDEN CAMS in this step. Arrow Metal end 420824 www.sauder.com/service Page 15...
  • Page 16 Now might be a TRACK into the groove. good time to refresh your drink. IMPORTANT The INTERLOCK TRACK is a safety - VIEW FROM BOTTOM - feature that must be installed in your unit. Post Large hole Groove Page 16 www.sauder.com/service 420824...
  • Page 17 Fasten four CABINET RIGHTS (35GA) to the RIGHT END (K). Use eight GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. å NOTE: The RAILS will overlap the INTERLOCK TRACK slightly. GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Roller end 420824 www.sauder.com/service Page 17...
  • Page 18 Step 14 å Fasten the RIGHT END (K) to the TOP (L), BRACE (O), and BOTTOM (P). Tighten five HIDDEN CAMS. å NOTE: Be sure the METAL PIN in the END inserts into the BRACE. Page 18 www.sauder.com/service 420824...
  • Page 19 Fasten the BALLAST (S) to the BOTTOM (P). Use three SILVER 1-1/8" FLAT HEAD SCREWS (10S). å NOTE: You should start each SCREW a few turns before completely tightening any of them. SILVER 1-1/8" FLAT HEAD SCREW (3 used in this step) 420824 www.sauder.com/service Page 19...
  • Page 20 Carefully turn your unit over onto its front edges. å Fasten the ENDS (J and K) to the METAL BRACKETS on the SKIRT (N). Use two BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (2 used in this step) Page 20 www.sauder.com/service 420824...
  • Page 21 Continue fastening the BACK to your unit using the NAILS through all remaining holes. NAIL (50 used in this step) The hole These holes must line must be here. up over the BRACE (O). STOP The edge spacing must remain even on the sides. 420824 www.sauder.com/service Page 21...
  • Page 22 Mark and drill a 1/8" hole a 3/8" hole into the wall. into the wall. Squeeze the wings together and tap the DRYWALL ANCHOR into the 3/8" hole in the wall. STUD INSTALLATION DRYWALL ANCHOR INSTALLATION Page 22 www.sauder.com/service 420824...
  • Page 23 SIDES (D635 and D636) and DRAWER BRACE (M67). Use five BLACK 1-9/16" FLAT HEAD SCREWS (30S). å Fasten the DRAWER BRACE (M67) to the DRAWER FRONT (E). Tighten one HIDDEN CAM. å Repeat this step for the remaining DRAWERS. 420824 www.sauder.com/service Page 23...
  • Page 24 Screw head - turn CAM to line up holes in Roller end the SLIDES with holes in DRAWER SIDES D635 Roller end D636 Drawer Slide GOLD 5/16" FLAT HEAD SCREW (16 used in this step) Center the screw in the oval hole. Page 24 www.sauder.com/service 420824...
  • Page 25 å NOTE: You should start each SCREW a few turns before completely tightening any of them. å Repeat this step for the remaining DRAWERS. BLACK 1-1/4" FLAT HEAD SCREW (12 used in this step) Curved edge 420824 www.sauder.com/service Page 25...
  • Page 26 RAIL. Before inserting the DRAWER, the lever must be in the up position. After inserting the DRAWER, the lever must be lowered onto the DRAWER SLIDE. Use the end of your Screwdriver if needed. Page 26 www.sauder.com/service 420824...
  • Page 27 #3. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. 420824 www.sauder.com/service Page 27...
  • Page 28 This completes assembly. Clean with a damp cloth. Wipe dry. l b s . l b s . l b s . l b s . Scan to rate and review your piece at Sauder.com Your opinion matters! Page 28 www.sauder.com/service 420824...
  • Page 29 Modèle 420824 Commode 4 Tiroirs Utilisez les instructions d’ a ssemblage en français avec les NOUS CONTACTER EN PREMIER schémas étape par étape du manuel d’instruction en anglais. AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN. Chaque étape en français correspond à la même étape en Nous faisons de notre mieux pour nous assurer que votre meuble anglais.
  • Page 30 Attention : Ne pas relever l'élément dans sa position verticale tournevis à chaque VIS avant de les serrer toutes à bloc. avant d'avoir fixé l’ARRIÈRE. L'élément risque de s'effondrer. Fixer l’EXTRÉMITÉ GAUCHE (J) au DESSUS (L). Serrer deux EXCENTRIQUES ESCAMOTABLES. Page 30 www.sauder.com/service 420824...
  • Page 31 à fleur avec la surface du mur. 4. Fixer l’unité au mur. Utiliser la VIS LONGUE à travers le trou dans la SANGLE DE SÉCURITÉ et dans le DISPOSITIF POUR PLACOPLÂTRE. Tourner plusieurs tours pour serrer complètement. 420824 www.sauder.com/service Page 31...
  • Page 32 Répéter cette étape pour les autres TIROIRS. ÉTAPE 24 REMARQUE : Prière de lire les informations importantes sur la sécurité figurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 32 www.sauder.com/service 420824...
  • Page 33 GABINETE DERECHO ..........4 35GA su referencia futura. Si necesita ponerse en D80 DORSO DE CAJÓN ...........4 GABINETE IZQUIERDO ..........4 35GB contacto con Sauder en LADO IZQUIERDO DE CAJÓN ......4 CAJÓN DERECHO .............4 D635 35GC cuanto a esta unidad, -1 con etiqueta CAJÓN IZQUIERDO ..........4...
  • Page 34 NOTA: Debe apretar cada TORNILLO unas vueltas antes de apretar cualquier tornillo firmemente. Precaución: No coloque la unidad en posición vertical hasta que se fije el DORSO. La unidad podría caerse. Fije el EXTREMO IZQUIERDO (J) al PANEL SUPERIOR (L). Apriete dos EXCÉNTRICOS ESCONDIDOS. Page 34 www.sauder.com/service 420824...
  • Page 35 4. Fije la unidad a la pared. Utilice el TORNILLO LARGO a través el agujero en la CORREA DE SEGURIDAD y en el ANCLAJE PARA EL DRYWALL. Gire varias vueltas para apretar completamente. 420824 www.sauder.com/service Page 35...
  • Page 36 Repita este paso para los CAJONES que quedan. PASO 24 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. Page 36 www.sauder.com/service 420824...
  • Page 37 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. 420824 www.sauder.com/service Page 37...
  • Page 38 SIEMPRE descargue los estantes y cajones, empezando con las superficies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 38 www.sauder.com/service 420824...
  • Page 39 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 40 CONTACT US FIRST BEFORE MAKING ANY RETURNS TO THE RETAILER. Dear Valued Customer: Register and review Thanks so much for choosing Sauder® furniture. I hope the your new product purchase and assembly process was a positive experience at Sauder.com and you feel good about the furniture you just built.
