12. INSTALLING COVER AND COVER RAILS
A. Make sure cover is centered on frame. There should be an equal amount of overhang at all four corners.
B. Insert the "S"- Hook on ratchet into hole on the leg bend. Insert the webbing into the spindle of the ratchet
and pull tight. Wind the ratchet so that the webbing overlaps itself.
C. Slide cover rails (#11105) through fabric pockets at each leg and reattach with clamps to each leg. Repeat
this on other side. Push down on cover rails to tighten cover, before tightening bolts completely.
D. Check and tighten Ratchets and Cover Rails monthly to ensure the cover is tight.
NOTE: The ShelterLogic
be oriented as shown below.
INCORRECT
REAR
Webbing and Ratchets Securing Cover
logo should
®
Middle Rib Cover Rail Clamps
11105
00690
CORRECT
11107
11130
11105
00690
Page 11
Fig. 12
COVER RAILS
11105
End Rib Cover Rail Clamps
11106
00690
05_GP-BA-XXXXXXA-015XXX12_E0
FRONT
11130
11105
