OPERATOR'S MANUAL
A Division of Snow Joe
, LLC
®
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
General Safety
m
WARNING!
This product is designed for outdoor use
by children between the age of 3-7. To reduce the risk of
injury, adult supervision is required at all times. Never use it
in roadways, around motor vehicles, steep inclines, steps,
swimming pools or other bodies of water. Do not use indoors.
Before starting up your ride-on SUV, please check it carefully
for any defects. If you find any, do not start up your product.
Contact your authorized Snow Joe
call the Snow Joe
+ Sun Joe
®
1-866-SNOWJOE (1-866-766-9563).
m
WARNING!
When using the ride-on SUV, basic safety
precautions should always be followed to reduce the risk of
fire, electric shock, and personal injury. These include:
• Limited to one person – Ensure that there is only
one person in the ride-on SUV at any given time. The
maximum weight capacity of this product is 66 lbs (30 kg).
Do not overload the product.
• Assembly – All assembly and adjustments must be
performed by an adult. Ensure that all fasteners are
securely tightened. Keep children away from all loose
parts and components.
• Know your product – Know how to start and stop the
product. Be thoroughly familiar with the controls and
ensure they are functioning properly.
• Avoid unintentional starting – Ensure the on/off button
is in the off position before installing the battery. Even if
you some how manange to, do not carry the ride-on SUV
with your finger on the on/off button. To avoid sudden
unintended acceleration, do not stand on the throttle.
• Moving parts – Keep hands and feet away from moving
parts such as the wheels, axles or motors.
• Gear shifter – Do not change gears while the ride-on SUV
is in motion.
© 2022 by Snow Joe
, LLC
®
All rights reserved. Original instructions.
KIDS RIDE - ON SUV
R
BLUETOOTH| FORWARD + REVERSE | REMOTE | LEDS
Model 24V-SUV1
+ Sun Joe
dealer or
®
®
customer service center at
®
• Hazards – Do not use on smooth floors such as marble.
Be aware of any potential obstacles or hazards. If the ride-
on SUV strikes an obstacle, follow these steps:
• Stop the ride-on SUV.
• Inspect for damage.
• Repair any damage before restarting the product.
• Dress properly – Do not wear loose clothing or jewelry as
such articles can become caught in moving parts. Tie up
long hair. Always wear shoes and a helmet.
• Sit properly – Do not stand on the seat or roll bar. Always
wear the 4-point racing harness while driving.
• Remove the battery – Turn off the ride-on SUV and
remove the battery when not in use, when clearing
jammed material, before making adjustments, before
storing, or before performing any maintenance.
• Store indoors – When not in use, the ride-on SUV should
be stored indoors in a dry place out of the reach of
children.
• Avoid water – Do not use the ride-on SUV in rain or in
damp or wet locations. Do not allow water or any other
liquids to get on the product or the remote.
• Noise and vibrations – Observe any noise-prevention
regulations. If the ride-on SUV should start to vibrate
abnormally, stop the machine and inspect it thoroughly for
damage.
Maintenance + Storage
m
WARNING!
Do not use detergents, acids, alkaline
solutions, bleaches or solvents such as acetone to clean your
tool. These substances may damage the plastic housing of the
machine.
• Inspect the tool – Before use, visually inspect the product
for any loose fasteners or damaged parts.
• Replacement parts – Inspect the product for worn,
missing, or damaged parts. When servicing this unit,
use only identical replacement parts. Replace or repair
damaged parts immediately. Contact the Snow Joe
Sun Joe
customer service center at 1-866-SNOWJOE
®
(1-866-766-9563) for assistance.
• Store indoors – When not in use, the tool should be
stored indoors in a dry place out of the reach of children.
SAVE THESE INSTRUCTIONS
1
EN
Form No. SJ-24V-SUV1-880E-M
+
®
