Airxcel 45000 Serie Consignes D'installation, D'utilisation Et D'entretien

INSTALLATION, OPERATION AND
MAINTENANCE INSTRUCTIONS
FOR 45000 SERIES HEAT PUMPS
TABLE OF CONTENTS
I.
General Information
II.
Heat Pump Sizing
III. Selecting an Installation Location
IV.
Installing the Roof Top Unit
A.
Standard Installation
B. OEM Top/Down Mounting
V.
Electrical Wiring
VI.
Installing Optional Heater Accessory
VII.
Installing Ceiling Assembly
These instructions are a general guide for installing the 45000 Series Coleman-Mach roof top Heat Pumps. For
specific Heat Pump details, it will be necessary to refer to ALL printed documents supplied with this unit.
These instructions are for the use of qualified individuals specially trained and experienced in installation of this type
equipment and related system components.
Installation and service personnel are required by some states to be licensed. PERSONS NOT QUALIFIED SHALL
NOT INSTALL NOR SERVICE THIS EQUIPMENT.
NOTE: The words "Shall" or "Must" indicate a requirement which is essential to satisfactory and safe product
performance. The words "Should" or "May" indicate a recommendation or advice which is not essential and not
required but which may be useful or helpful.
WARNING! – SHOCK HAZARD To prevent the possibility of severe personal injury or equipment damage due
to electrical shock, always be sure the electrical power source to the appliance is disconnected.
CAREFULLY FOLLOW ALL INSTRUCTIONS AND WARNINGS IN THIS BOOKLET TO
AVOID DAMAGE TO THE EQUIPMENT, PERSONAL INJURY OR FIRE.
WARNING! Improper installation may damage equipment, can create a hazard and will void the warranty.
The use of components not tested in accordance with these units will void the warranty, may make the equipment
in violation of state codes, may create a hazard and may ruin the equipment.
P/N: 1980-054
RV Products Division
2
2
2
2
2
4
4
6
6
(9600 Series)
IMPORTANT NOTICE
VIII.
System Checkout
IX.
Operation and Maintenance
i.
General Information
ii.
Control Panel
iii. Operation
iv. Maintenance
v.
Wall Thermostat Identification and Operation
vi. Warranty Service
X. Optional Extended Warranty
6
10
10
10
11
11
12
12
28
04-26-2016
