ID Buzz EB
Produktübersicht
D
Elektro-Einbausatz für Anhängerkupplung / 13-polig / 12 Volt / ISO 11446
Product overview
GB
Electric wiring kit for towbars / 13-pin / 12 Volt / ISO 11446
Aperçu des produits
F
Faisceau pour attelage / 13 broches / 12 Volt / ISO 11446
Cerrellata dei prodotti
I
Cablaggio elettrico per ganci di traino / 13 poli / 12 Volt / ISO 11446
Descrpción del producto
E
Kits eléctricos para enganches de remolques / 13 pins / 12 Volt / ISO 11446
Productoverzicht
NL
Elektro-inbouwset voor aanhangerkoppeling / 13-polig / 12 Volt / ISO 11446
© JAEGER automotive GmbH / Chromstrasse 90 / D-33415 Verl / FON: +49 5246-9210-0 / FAX: +49 5246-9210-20 /e-mail: info@jaeger-automotive.de
10/22
21270586
ID Buzz Cargo EB
VW
10/22
