Stid ARC-W45-G/U04-5AA1 Notice D'installation

UHF
Desktop Reader
Installation instruction
ARC-W45-G/U04-5AA1: 865 - 868 MHz
ARC-W45-G/U04-5AA1M: 865.7 MHz Morocco
Communication: USB
Cable output: USB 2.0 cable – Length 1.50 m / 4.9 ft – Connector type A
Direct Current
:
Windows ≥ 10:
Windows automatically detects the reader as a 'USB COMPOSITE DEVICE' and installs the driver.
Windows < 10: the driver is automatically installed with a STid Software, if no STid software are installed:
- Contact support@stid.com to obtain the 2 drivers files:
- Connect the reader to the USB port COM of PC.
- Copy the 2 files in the directory: C:\Windows\INF.
Bidirectionnal: by default, the reader is delivered in bidirectional SSCP mode. More details about reader communication are available in the protocol
specification: Spec_Protocole_SSCP_UHF_INDUS-Vx.x.
Keyboard emulation: the reader can be used in keyboard emulation: wedge mode. See Configuring the reader in Wedge mode.
The readers can be
https://stid.com/images/UWedgeConfv110_setup.zip
In this mode the reader emulates a keyboard and displays in the active window the characters received from the serial link.
The reader is delivered with the default parameters in bold in the table.
1- Set the options needed (if different than the defaults).
2- Send the 'Keyboard emulation ON' command.
Command
Update
Language (set)
Type case (set)
Numlock (set)
Info (get)
Timing (set)
Carriage Return (set)
SOF (set)
EOF (set)
Reset to default
EPC Private key (set)
Keyboard emulation (set)
General tolerance following ISO NFT 58-000 standard.
STid reserves the right to make change without notice, for the purpose of product improvement.
UHF
Lecteur de table
Notice d'installation
cdc.cat
Configuring the reader in Wedge mode
configured with STid
Description of the command
Put the converter in update mode.
Changes the keyboard layout.
Chooses whether the alphabetical characters are displayed
on the screen in uppercase or lowercase.
Chooses which numerical keys are used: those on the
numerical keypad or those above the alphabetical keys.
Shows the current configuration (version, baud rate, etc.).
Define the time between the sending of 2 characters.
Switches the carriage return off or on or on with release
before key pressed.
Add the character " – " at the beginning of the frame.
Add the character " . " at the end of the frame.
Set the reader to factory default.
Set the user ID security reading mode.
Enables / disables keyboard emulation mode.
When the reader is in Keyboard emulation ON, the only
command accepted is Keyboard emulation
1.09 in / 27,7 mm
© STid - 20 PA des Pradeaux FR13850 Gréasque - NI1148x04- Page 1 sur 7 - Ed. 28/11/2022
Product references
ARC-W55-G/U04-5AA1: 902 - 928 MHz
ARC-W55-G/U04-5AA1AU: Australia
ARC-W55-G/U04-5AA1NZ: New Zealand
ARC-W55-G/U04-5AA1PE: Peru
ARC-W55-G/U04-5AA1PH: Philippines
Characteristics
Driver installation
fsl_ucwxp.inf
and .
Communication
-USB Wedge Configuration
OFF.
Dimensions
3.15 in / 80,0 mm
UHF
Lector de mesa
Procedimiento de instalación
conforme con NOM-024 -SCFI-2013
tool available on
Options
The file firmware.bin is supplied by
STid.
- Français (AZERTY)
- English (QWERTY)
- Uppercase
- Lowercase
- On (use numeric pad)
- Off (use keyboard nb)
between 20ms and 1s
- Off
- On
- On + Released
- Off
- On
- Off
- On
- Plain
- Enciphered + value Private key
- Off (disable)
- On (enable)
US
FR
ES
download link:
