STAINLESS-STEEL BASKET WITH RAILS
TOOLS REQUIRED:
#2
#2
#2
CARE AND MAINTENANCE:
Clean with a damp cloth and
wipe parts dry.
WATCH TUTORIALS OF OUR
PRODUCTS BEING INSTALLED
WWW.REV-A-SHELF.COM/VIDEOS
No.
A
B
A.
INSTALLATION INSTRUCTIONS: STAINLESS-STEEL BASKET WITH RAILS
PARTS LIST
Description
Wood Rails
Stainless-Steel Basket
B.
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
Qty.
2
1
I-4SSB-1224
