CONTROL MENU
MENU
A001- A512
Addr
CHnd 4CH
Aut1
Aut2
SLnd
SL 1
Soun
SPEd SP01-25
SEnS 00-99
LEd OFF
ON
dISP YES
NO
REST YES
DMX CHANNELS
CHANNEL FUNCTION
1 MOTOR RUNNING
AUTO MODE
2
SOUND MODE
3 AUTO 1 SPEED
4 RESET
DESCRIPTION
DMX512 address setting
4CH
Motoring mode 1 ran at a Sped set speed
Automatic mode variable speed operation
Slave mode
Sound active mode
The automatic rotation speed is set from slow to fast
Adjust the sensitivity of sound active
Turn off LED display after 5 seconds
LED display on all the time
Display reverse
Display forward
System Reset after 5 seconds
VALUE DESCRIPTION
000-005 No function
006-126 Clockwise rotation from fast to slow
127-128 No function
129-249 Anti-clockwise rotation from slow to fast
250-255 No function
000-049 No function
050-099 Auto 1, Channel 3 controls the speed
100-199 Auto 2
200-255 Sound
000-255 Auto 1 speed, from slow to fast
000-249 No function
250-255 System reset after 5 seconds
