Permobil Compass Power Mount Manuel D'utilisation page 3

CONTACT INFORMATION
The Comfort Companies, LLC
1960 South Calhoun Road
New Berlin, Wisconsin 53151 USA
Phone:
U.S.A.: 800-736-0925
Outside the USA: 262-432-0830
Fax: 406-522-8563
Customer Support:
orders.comfort@permobil.com
permobil.com
WARNING
Indicates that not following the specified procedure could
lead to potentially hazardous conditions resulting in
serious injury.
CAUTION
Indicates that not following the specified procedure could
lead to potentially hazardous conditions resulting in minor
to moderate injury or damage to the equipment or other
property.
INCIDENT REPORTING
In the event of a serious incident or injury, contact
Customer Support.
PLEASE NOTE
Supplier: These instructions must be given to the user
of this product.
Operator (Individual or Caregiver): Before using this
product, read the instructions and save for future
reference.
Products may be covered by one or more U.S. and foreign
patents and trademarks, including Permobil
Corpus , Compass , ACTA-BACK
® ®
Shape and COMFORT-TEK
® ®
Quickie is a registered trademark of Sunrise Medical, LLC.
®
BOA is a registered trademark of Boa Technology Inc.
®
Quantum , Quantum Rival
® ®
are registered trademarks of Pride Mobility Products
Corporation.
Product information is changed as needed; current
product information is available at permobil.com.
The Comfort Companies, LLC is a part of Permobil.
© 2019, 2021 Permobil
Rev. 2021-06-04
Compass Power Mount Hardware Operation Manual
Thank you for choosing
, BodiLink
®
, ACTA-EMBRACE , Tru-
® ®
.
, Q6 Edge and TRU-BALANCE
®
Compass Power Mount.
®
TABLE OF CONTENTS
Intended Use
Important Safety Information
Parts Detail
Compatibility and Height
Seat Depth
Installation - Pre-Assembled
Installation - Mounting Bracket and Track
Alignment
Installation - Quantum, Permobil, Rovi
Installation - Quickie
Installation - Back Support Assembly
Back Support Adjustments
Assembly - ACTA-Relief Shell Spacers
Assembly - ACTA-Relief Shell Bracket and Track
Spacer
Assembly - ACTA-BACK and ACTA-EMBRACE
Shell Bracket
Assembly - Tru-Shape Shell Bracket
Cleaning and Alignment - Tracks
Cleaning
Inspection, Reuse, Storage, Disposal,
Replacement Parts, Warranty, and
Replacement Procedure
Français
Español
,
®
®
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
37
