Quick Installation Guide
Access Point Mount Accessory
APM-100 / APM-110
Note: Images are for demonstration only, and may differ from your actual products.
© 2025 TP-Link 7106511814 REV1.0.0
Mount the AP
For additional rotation needs of the AP, connect the mount accessory between your AP bracket and mounting bracket.
APM-100 is used for demonstration. APM-110 can be installed in a similar manner.
Option 1: Pole Mounting
1
Option 2: Wall Mounting
1
2
3
2
3
APM-100
1×
4×
Vertical adjustment: ±45°
Horizontal adjustment: ±45°
Note: The actual adjustment angle may be affected by the product antenna and installation position.
4
4
APM-110
1×
4×
Vertical adjustment: ±90°
Horizontal adjustment: ±45°
5
5
