STEP 6
Quick
Assembly
Tip
LOCK
18
2
×10
×4
Proper orientation of CAM LOCK
6.1 Attach (C) to (L), (B) & (F) with (2) as illustrated.
6.2 Attach (D) to (L), (B) & (F) with (2) as illustrated.
6.3 Use (18) to cover cam lock hole as illustrated.
2
C
18
L
B
D
F
12
