TOYOTA
®
U s e r m a n u a l
Assemble the extension cable into a fixing frame of the horizontal speaker driver (on IS 690TOY, IC 165TOY and
IC 690TOY only)
"+" and "-" terminals at the back of
the speaker driver
Pass the connector cable in the
dedicated space
Fixing diameter
Two fixing diameters (A and B)
According to the horizontal and vertical
installations in the door panels
All manuals and user guides at all-guides.com
plug&plAY inTegrATiOn
TOYOTA
connector / extension cable
®
supplied with the kit
Connection of the spades on the back
terminal
267.40
217.50
190.45
199.40
217.50
