Poly Studio X30 Montage page 5

Wall - Bottom of Display Inverted Mount
1342-86361-003
1342-86361-004
Inverted Mount Only
Poly Studio X30 Mounting Kit with Inverted Mount Option Setup Sheet
(4) #8 × 1"
Screw
1342-86359-003
(2) M4 × 8
Screw
Inverted Front Panel
140 mm 152 mm
127 mm 140 mm
114 mm 127 mm
(4) #8 × 7/8"
Plastic Anchor 76 mm -
152 mm
¼-20 Thumb
Screw
102 mm 114 mm
89 mm 102 mm
76 mm 89 mm
Wall
114 mm -
152 mm
140 152
mm mm
127 140
mm mm
114 127
mm mm
76 mm -
114 mm
102 114
mm mm
89 102
mm mm
76 89
mm mm
5
