Buffalo TS-RIGL/R5 Guide D'installation Rapide page 4

EN
TeraStation Layout
Front With Panel Removed
Fig: 2
Back Panel
UPS
All manuals and user guides at all-guides.com
Hard Drives
(Squeeze tabs to release)
USB in
Ethernet
(to router)
Init Button
(Hold down to reset all settings)
2
1
Power Cable
Fig: 3
