5 Slide the upper handle frame into lower handle then
depress the small button at the end of the upper handle
frame, push and insert into lower handle until it snaps
securely into place (Figs. 4 – 5).
Fig. 4
Fig. 5
Push
button
6. Connect the high-pressure hose to the water outlet on the
washer (Fig. 6).
Fig. 6
Upper
handle
frame
7. Fit the stainless steel lance into the trigger gun and rotate
the collar until the two parts are completely locked (Fig. 7).
Lower handle
Fig. 7
Stainless
steel lance
Upper
handle 8. Connect the high-pressure hose to the trigger gun
frame
(Fig. 8).
Fig. 8
Lower
handle
8
(REAR)
High-pressure hose
Trigger gun
High-pressure
hose
High-pressure
water outlet
Collar
Trigger gun
