RVM-64CM125
TV Ceiling Mount
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
All manuals and user guides at all-guides.com
Reduce
Reuse
Recyle
!
CAUTION:
THE MAXIMUM LOADING
WEIGHT IS 125 LBS. USE WITH PRODUCTS
HEAVIER THAN THE MAXIMUM WEIGHT
INDICATED MAY RESULT IN INSTABILITY AND
POSSIBLE PERSONAL INJURY.
Max Screen Size: 70"
V1
P1
Publicité
Manuels Connexes pour Rapid video mounts RVM-64CM125
Sommaire des Matières pour Rapid video mounts RVM-64CM125
- Page 1 All manuals and user guides at all-guides.com RVM-64CM125 Reduce TV Ceiling Mount Reuse INSTRUCTION MANUAL Recyle MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS CAUTION: THE MAXIMUM LOADING WEIGHT IS 125 LBS. USE WITH PRODUCTS HEAVIER THAN THE MAXIMUM WEIGHT INDICATED MAY RESULT IN INSTABILITY AND POSSIBLE PERSONAL INJURY.
- Page 2 Tampoco prevé todas las posibles contingencias relacionadas con la instalación o el uso de este producto. La información que contiene este documento queda sujeta a cambio sin aviso previo o compromiso alguno. RAPID VIDEO MOUNTS no ofrece ninguna garantía, ni expresa ni implícita, respecto de la información aquí incluida. RAPID VIDEO MOUNTS no se responsabiliza de la precisión de la información provista en este documento, ni tampoco de que sea completa o suficiente.
- Page 3 HARDWARE PRODUCT NUMBERS All manuals and user guides at all-guides.com SQUARE M5 x 30 M6 x 30 M8 x 30 M4 x 30 M8 x 15 M6 x 15 M4 x 12 M5 x 12 SPACER WASHER M8 x 45 ALLEN KEY M5 SET SCREW ALLEN KEY...
- Page 4 STEP 1- FLAT BACK TV (UNIVERSAL MONITOR PLATE) All manuals and user guides at all-guides.com Connect Universal Monitor Plate to TV Conecte el adaptador al monitor Connectez l'adaptateur au moniteur STEP 1- CURVED BACK TV (UNIVERSAL MONITOR PLATE) Connect Universal Monitor Plate to flat panel Conecte el adaptador al monitor Connectez l'adaptateur au moniteur Spacers can also be used to...
- Page 5 STEP 1- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE MONITOR KIT All manuals and user guides at all-guides.com ARE TOO LONG Diagrams show three options for using additional washers if hardware screws are too long to properly tighten into back of television.
- Page 6 STEP 1- CENTER UNIVERSAL MONITOR PLATE All manuals and user guides at all-guides.com Monitor Plate must be centered (horizontal plane) on back of TV Secure vertical rails to horizontal chrome rod on Monitor Plate with pre-installed screws.
- Page 7 STEP 2- ASSEMBLE THE CEILING MOUNT All manuals and user guides at all-guides.com...
- Page 8 STEP 3- WOOD STUD INSTALLATION All manuals and user guides at all-guides.com Wood Pilot Pilot Hole Size Pilot Drill Depth 7/32” inch 2.75 inch 5.5 mm 70 mm...
- Page 9 STEP 4- ATTACH THE PIPE ASSEMBLY AT THE CEILING PLATE. All manuals and user guides at all-guides.com M5 Set Screw Allen Key 2.5mm Adjust the pipe assembly to Rotate the pipe assembly to the best direction , then tighten the ceiling plate, assemble the the set screw with the security two parts.
- Page 10 STEP 5- LIFT AND HANG THE MONITOR PLATE AT THE PIPE ASSEMBLY. All manuals and user guides at all-guides.com Secure Acorn Nut and Washer on a) Rotate handle clockwise as far as Monitor Plate to Pipe possible. Assemble (snug b) Pull handle to side laterally tension only) (against spring tension) and rotate counter-clockwise as far as possible.
- Page 11 STEP 6- CABLE MANAGEMENT All manuals and user guides at all-guides.com...
- Page 12 Esta garantía se aplica a los residentes de los Estados Unidos que realizaron la compra en un distribuidor autorizado de RAPID VIDEO MOUNTS. Esta garantía cubre los productos RAPID VIDEO MOUNTS de los defectos de materiales y de mano de obra por un periodo de 5 años. RAPID VIDEO MOUNTS, a su exclusivo criterio, reparará o reemplazará...
