STEP C
CROSSBAR
Assemble the
CROSSBAR ,
Attaching tubes
12-6 to M7,M2 & M5 connectors.
M2
M2
M5
M5
Ensure arrows on all the M7 connectors are pointing upwards
12-6
12-6
M7
12-6
M2
M2
M7
M5
M5
Assembled CROSSBAR should have a gentle upward arc
