User manual
• 2.1 Display and menu details.
* When DMX is connected, the menu buttons are disabled.
Buttons :
MENU : Browsing menu pages
UP : to go up or increase settings values
DOWN : to go down or decrease settings values
ENTER : to enter a submenu, validate or save a setting
Pages under menu :
•Page 1: "Ready to fog" The machine is ready to work
•Page 2: "Interval Set" Set the interval of timer mode, adjustable from 5~200s
•Page3: "Duration Set " Set the duration of timer mode, adjustable from 5~200s
•Page 4: "Timer Out " Set the output volume of "Timer" mode, adjustable from 1%~100%
•Page 5: "Volume Out " Set the output volume of "Volume" mode, adjustable from 1%~100%
•Page 6: "Fan Speed " Set the fan speed, adjustable from 1%~100%
•Page 7: " Fluid Sensor " Turn on/off no-fluid protection function
•Page 8: " DMX512 Address " The DMX address can be set up from 1 to 512;
•Page 9: " Wireless Set " To turn on/off the wireless function
•Page 10: "Direct Timer " Turn on/off " Direct Timer " function. When power is on again, continue " Timer "
working mode from last time power cut off
• Under any setting pages, press STOP to exit or return to the page one.
• When the unit is working, press STOP to stop running and return to the page one.
• After enter into different setting pages, press UP and DOWN to change the value.
• When it is in the page one, press TIMER button to enter into timer mode, the detail is as below:
"Interval 10s "
•
"Duration 10s "
•
• The two pages will display circularly, according to the time (such as 10 s) will be subject to the current set of
values (1 and 2 set of page).
• In the condition of timing, the smoke volume is controlled by the Timer Out.
• When in the first page, it's available to press " VOLUME ", and ready to
• work, description is as below:
• When enter the work stage, the smoke volume is according to the "Volume Out ".
X-SW1500
Ultrasound Low Fog
12 12
12
