7. Connect your cables according to your need
⑨
The cable terminal
is available for all your required wired connections.
Please be careful during the process and gently screw the wires to the terminal block. There is no need to
force the screws, simply tighten enough for cables not to become loose.
✦ Power supply (12-24VDC +/-)
The caller station can run on batteries only. The observed battery life is 12 to 18 months.
Additionally or alternatively, you can connect a 12-24VDC power supply. This power can be provided via any source
(optional adaptor, gate power, solar panel, ...) as long as it is Direct Current (DC) and 12 or 24V.
If you use both batteries and DC power supply, the batteries will then act as backup battery (in case of power failure).
If connected to DC power, your caller station will benefit from two extra features:
✦ Night lighting: When it gets dark, the caller station call button
②
keypad buttons
, on concerned models only)
✦ Wireless gate release always available: On DC, the wireless gate release is always available, even when you are
not in communication, by a long press on the
On battery, these features will automatically be turned off to save battery life.
DANGER: Under no circumstances should AC mains Voltage (220V) be directly connected to the terminal
⑨
blocks
.
✦ Optional external aerial
If necessary, an optional external aerial can be added to your installation. This aerial improves the wireless range by
avoiding the main obstacles in your environment: mounting wall, metal gate, wireless interference, trees, buildings, ...
By using an external aerial, your wireless signal will be sent from a better starting point. Simply screw the add on
aerial to the loose cable
external aerial, please set the
IMPORTANT: If you are not using the optional external aerial, the switch must be on
the built in aerial). The connector cable
station (with the red tip).
⑬
⑩
(remove the red tip) at the back of the caller station. For your caller station to use the
⑥
EXT
switch to
.
⑩
will not be in use and can be left loose at the back of the caller
①
will light up to welcome your visitors (and the
(on batteries, unlock is only available during communication)
12
INT
(the system will use
