ASSEMBLY INSTRUCTIONS
1. Attach fixture body (A) to base body (B) with
four machine screws (CC). (See Fig. 1.)
Hardware Used
Machine Screws
BB
2. Ground wire connection guide (See Fig. 2.):
• Attach copper wire to gound wire with wire
connectors (AA).
Hardware Used
Wire Connectors
AA
