TecTake 401156 Notice D'utilisation

EN
MOTORCYCLE POSITION STAND
INSTRUCTION MANUAL
TecTake GmbH,
Tauberweg 41, D-97999 Igersheim, Germany
401156
ORIGINAL INSTRUCTION MANUAL
RETAIN FOR FUTURE REFERENCE
Parameter
TYRE DIA：17"~21"
TYRE WIDTH：90-130 mm
Introduction
This motorcycle position stand suits for 17"~21" and tire width
90-130mm motorcycle tires use, can be placed on any level
ground, to fix motorcycle and keep it from moving, it is easy to
use, convenient and save labor.
Using
1. Put this stand on the suitable level, and adjust it according to
the motorcycle tire size.
2. put the movable bracket on the ground horizontally, then push
the motorcycle onto the movable bracket, then forward into the
position stand, so it is ok for motorcycle position setting.
3. Afterward insert the lock pin to hole of the movable bracket, so
that keep the motorcycle from being back off.
4. Opposite above, move the motorcycle from the position stand.
Warning
1. Do not use it for the motorcycle tire which not suits the
motorcycle position stand's specification.
2. Do not use it on the leaning ramp.
3. Save this stand appropriately, and do not use it when in
damage.
