GB
• Symbols appearing on your product may not be
removed or covered. Information on the product
that are no longer legible must be replaced imme-
diately.
Read and observe the operating instructions
before commissioning.
Risk of damage to the eyes! Never look di-
rectly into the LED.
Your device in an overview
Note: The actual appearance of your prod-
uct may differ from the illustrations.
► P. 3, fig. 1
1. Tool receiving socket
2. Torque controller
3. Control lights for the charging station
4. Release button for rotating handle
5. Connection for the charger
6. Rotation direction reversing switch
7. On/off switch
8. LED
Scope of delivery
• Lithium ion cordless screwdriver
• Battery charger
• Bits (4 ×)
• Carrying bag
• Operating Manual
Charging the Rechargeable Battery
• The battery must be charged prior to the first start-
up. (Charging period: ► Technical data – p. 14).
– Charge up the product by connecting it to the
charger.
• The charging status is displayed by the control
lights (3):
– All control lights are illuminated: The battery is
fully charged.
– Only the red and yellow control lights are illumi-
nated: Charging status at approx. 50%.
– Only the red control light is illuminated: Battery
is empty.
NOTICE! Risk of damages to the device!
Frequently activating the on-off switch can
damage the battery.
Operation
– Place the tool into the tool receiving socket (1).
– Press and hold the on-off switch.
– Set the desired rotation direction on the rotation
direction reversing switch (6).
– Set the required torque via the torque control-
ler (2) in increments of 1 to 9.
– The handle can be locked in two different posi-
tions. Do this by holding down the release but-
ton (4) and rotating the handle.
NOTICE! Risk of damages to the device!
The rotation direction reversing switch may
only be operated when the device is shut off.
14
Preparing for disposal
Removing the battery
► P. 3, fig. 2
At the end of the device lifetime, you should remove
all batteries before disposing of the item.
– To remove the batteries from the unit, operate the
on/off switch until the batteries are fully dis-
charged.
– Remove the screws on the housing and remove
the housing shell.
– Separate the connections on the batteries (9) and
remove.
– Dispose of the batteries in accordance with the
regulations.
Disposal
Disposal of the appliance
A crossed-out wheelie bin icon means: Bat-
teries and rechargeable batteries, electrical
or electronic devices must not be disposed of
with household waste. They may contain
substances that are harmful to the environ-
ment and human health.
Consumers must dispose of waste electrical devices,
spent portable batteries and rechargeable batteries
separately from household waste at an official collec-
tion point to ensure that these items are processed
correctly. The product can be returned free of charge
in accordance with the legal requirements, for exam-
ple through a municipal waste disposal company or a
dealer.
Batteries, rechargeable batteries and lamps
that are not permanently installed in waste
electrical equipment and can be removed in
a non-destructive way must be removed and
disposed of separately before disposal of the equip-
ment. Lithium batteries and rechargeable battery
packs of all systems are only to be handed in to the
waste collection points in a discharged state. The bat-
teries must always be protected against short circuits
by taping off the poles.
All end users are responsible for deleting any per-
sonal data stored on waste devices prior to their dis-
posal.
Disposal of the packaging
The packaging consists of cardboard and
correspondingly marked plastics that can
be recycled.
– Make these materials available for recy-
cling.
Technical data
Part number
Rated voltage
idle speed
max. torque
Sound power level (L
WA
Sound pressure level (L
Vibration**
Battery type
350798
3,6 V
-1
230 min
3 Nm
)* 72,7 dB(A)
(K = 3 dB(A))
)* 61,7 dB(A)
PA
(K = 3 dB(A))
0,39 m/s²
(K = 1,5 m/s²)
Li-Ion, 1,3 Ah
