7.3
Belt adjustment path ((Fig. 6)
▪
Check if the sanding belt is running centrally before starting the work.
▪
Run the file at no load speed and turn the centralizing knob either clockwise or anti-
clockwise to adjust the belt tracking until the sanding belt is running smooth.
7.4
Connect the dust bag (Fig. 7)
▪
This machine is fitted with a dust extraction outlet and a collection bag.
▪
We recommend using this facility is at all times, as well as using an approved face mask.
It will make you work cleaner.
▪
First place the extraction outlet, and then fit the dust collection bag onto the outlet.
8 OPERATION
8.1
Adjust the angle of the arm (Fig. 8)
▪
Before adjusting the angle of the arm, please make sure that the machine is turned off
and unplugged.
▪
The operator can adjust the arm in any angle according to the position or the shape of
work pieces, and then fix it into place.
▪
Loosen the angle adjustment lever, then you can lift up the arm. Rotate the arm along the
pivot to the desired position, then lock the angle adjustment lever and fix the arm into
place.
8.2
Switch operation (Fig. 9)
▪
The tool is operated by pressing/releasing the main switch. The machine will start by
pressing the main switch and stop when releasing the main switch.
▪
Press the lock button and the main switch at the same time to lock the swith into position
and the machine will work continuously.
▪
Press the main switch all the way to the end and then release it to unlock the machine
again.
8.3
Speed controller (Fig. 10)
▪
The speed can be adjusted between 300 m/min and 1700 m/min through rotating the
speed controller from 1 to 6.
▪
Adjusting the controller from 1 to 6 will accelerate.
▪
Adjusting the controller from 6 to 1 will slow down.
▪
Please choose the right speed according to the work piece.
8.4
Sanding operation (Fig. 11 and 12)
▪
Secure the work piece to prevent it from moving under the sander belt.
▪
When starting or stopping the machine, do not let the tool contact with the work piece.
Otherwise, it will result the damage of the sander belt or it will make the machine getting
out of control.
▪
When operating the machine, be careful to avoid any part of your body to come into
contact with any of the moving parts of the machine or belt.
▪
Hold the machine with both hands in front of you and away from you, and assume a
balanced posture.
▪
Press the main switch and allow the motor to reach full speed. Hold the machine parallel
to the work piece. Gently bring the belt in contact with the work piece. Do not force tool.
The weight of the sander supplies adequate pressure. Applying additional pressure will
slow down the motor, rapidly wear out the sanding belt and reduce the sanding speed a
lot.
▪
Avoid contact with the sanding belt at any time.
