Flexa ROOMIE 81-39301 Serie Instructions De Montage page 2

x36 x3 x40 x4 x18 x12 x24
A B C D E F G
Ø6x43,5mm Ø4,0x30mm Ø8x30mm 3,5x20mm Ø6,3x10,5mm Ø15x12,2mm Ø16,3x13,1mm
3934-060451 3903-40030 3930-08030 4013-007 3907-63011 3933-150122 3933-150131
74,5x72x43,5cm
2
x2
4301-16068810-x
4301-16072015-x
1
x2
3
4309-0307004
