3. TECHNICAL DATA
Electrical characteristics of switch-disconnectors in metal enclosure (2P, 3P, 4P)
Built-in control
SCAME
Command
Duly rated
Series
current
switch-
based on the
disconnector
category
Fam. 590
Table 1 - Electrical characteristics of switch-disconnectors (2P, 3P, 4P).
For frequencies > 100Hz the rated current is declassed to 25%. ( PER INGLESE )
Technical data of external earth terminal
The threaded hole to be used in order to connect the enclosure to the earth conductor is found on an external wall; use a screw
and a pre-isolated wire terminals and anti-rotation bracket supplied with the device as shown in figure 5, connection section and
tightening torque see Table 2.
Technical data of power/earth terminals
Power terminals / connectable wires and tightening torques
Power terminal version
20A
32A
40A
63A
Internal earth terminal
External earth terminal
Table 2 - Terminals for unprepared rigid
and flexible copper cables / flexible cables with terminals.
MP37129
Technical data
Rated current
Isolation voltage (UI)
415V
AC22A
690V
415V
AC23A
690V
400V
AC3
690V
Nominal frequency
Cable section to be used
Tightening torque (Nm)
(rigid or flexible) mm²
4
6
6
10
Maximum section 10
Section 4 – 6
Rated current
590.XHGE/ 590.XHGE/
XHEM200X XHEM320X
20A 32A
690V 690V
20A 32A
20A 32A
20A 32A
20A 25A
18A 25A
12A 18A
50/60Hz 50/60Hz
0,8
0,8
0,8
3,6
2
1,2
Fig.3: Position of external earth terminal.
13
590.XHGE/ 590.XHGE/
XHEM400X XHEM630X
40A 63A
690V 690V
40A 63A
32A 63A
35A 63A
25A 30A
28,5A 40A
20A 25A
50/60Hz 50/60Hz
