WARNING
before performing any assembly or
adjustments, or changing accessories. Such
preventive safety measures reduce the risk of
starting the tool accidentally.
WARNING
product damage due to a short circuit, never
This 18V To 24V Adapter must be used only with the battery packs listed below:
2.0Ah
2.5Ah
FX0311
FX0111
NOTICE: Please refer to the battery pack manuals for detailed safety and operating
instructions.
TO ATTACH/DETACH BATTERY PACK (FIG. 2)
To attach the battery pack:
Align the raised rib on the battery pack with
the grooves in the adapter and then slide the
battery pack onto the adapter.
When placing the battery pack
NOTICE
onto the adapter, be sure that the
raised rib on the battery pack aligns with the
groove inside the adapter and that the latches
snap into place properly. Improper attachment
of the battery pack can cause damage to
internal components.
To detach the battery pack:
Depress battery-release button located on the
front of the battery pack to release the battery
pack. Pull the battery pack out and remove it
from the adapter.
WARNING
accessories not recommended for use with
this tool. Any such alteration or modification is
misuse and could result in a hazardous
condition leading to possible serious injury.
Detach the battery pack
and adapter from the tool
To reduce the risk of fire,
personal injury, and
3.5Ah
5.0Ah
FX0321
FX0121
Do not attempt to modify
this adapter or create
ASSEMBLY
immerse your battery pack or adapter in
fluid or allow a fluid to flow inside them.
Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and
bleach or bleach-containing products, etc. can
cause a short circuit.
Intended use: The 18V To 24V Adapter is
designed to connect FLEX 24V battery packs to
FLEX 18V polisher PE 150 18.0-EC, XCE 8 125
18-EC, XFE 15 150 18-EC.
Battery Pack
6Ah
FX0331
FX0221
Fig. 2
Attach
Battery-release
Button
-7-
8.0Ah
10Ah
FX0341
18V To 24V Adapter
12Ah
FX0231
Detach
