System Map: Bottom & Rear Views
1
3
Model A
1
3
Model C
2
Figure 12
Bottom & Rear
Views
1. Vent
2. RJ-45 LAN Jack
3
3. Speakers
2
Bottom Cover Removal Warning
Do not remove any cover(s) and/or screw(s) for the purposes of de-
vice upgrade as this may violate the terms of your warranty. If you
need to replace/remove the HDD/SSD/RAM etc., for any reason,
please contact your distributor/supplier for further information.
3
To prevent your computer from overheating make sure nothing
blocks any vent while the computer is in use.
1
3
Model B

Overheating
2
3
15
