UEi Test Instruments DL589 Manuel D'instructions page 12

TEMP
• Disconnect test lead probes from voltage source and meter.
• Move Input Jack Locks to "TEMP" setting.
• Use K-Type thermocouple temperature probes only.
• Stated accuracy does not account for thermocouple accuracy.
Features:
Range
-328˚F to 999˚F
(-200˚C to 999˚C)
1000˚F to 2462˚F
(1000˚C to 1350˚C)
• Buzzer sounds at less than < 40Ω.
WARNING
• Do not measure resistance on a live circuit.
Features:
Open Circuit V <1.00V
Threshold Approx. <40Ω
Temperature F˚/C˚
CAT IV
600V 600A
DL589
A
Temp
µA
V
SELECT
Low Z
AUTO
PEAK
True RMS
30V
T
T
1
TEMP
SELECT
BT
Resolution
0.1°F (0.1˚C)
1°F (1˚C)
Continuity
CAT IV
600V 600A
DL589
A
Temp
µA
V
SELECT
Low Z
A
AUTO
V
PEAK
True RMS
30V
T
T
2
1
TEMP
SELECT
BT
Temp
• Default = T1
• Press SELECT x1 = T2
A
V
• Press SELECT x2 = T1 - T2
F
T
1
• Press and hold RANGE = ˚F or ˚C
• Readings show on lower display
2
Accuracy
±(1.0% +3.6˚F)
±(1.0% + 2.0˚C)
±(1.0% +3˚F)
±(1.0% + 2˚C)
• Default =
• Press SELECT x1 =
Overload Protection
600V RMS
12
Overload Protection
30V RMS
