A
C
D
E
F
DL599
G
H
SELECT
BT
AUTO
I
J
K
L
A. Clamp: Measure inductive AC/DC current. Opens to 1.25" (32.0mm).
B. Conductor Alignment Marks: Use to aid the visual alignment of a
conductor when measuring inductive amperage. Greatest accuracy
is achieved when the conductor inside the clamp is centered at the
intersection of these marks.
C. Worklight: Lights clamp area in dark work environments.
D. Category Max Indicator: Maximum CAT Rating for clamp jaw.
E. NCV Alert Light: Indicates voltage when in NCV (Non Contact Voltage)
mode and High Voltage alert.
F. Clamp Lever: Opens and closes current clamp jaw.
NOTE: The clamp uses a high-tension spring to close the jaw. Do not
allow fingers or objects to become pinched in the base as the jaws close.
G. Rotary Selector Dial: Set Rotary Selector Dial desired function
H. SELECT/Wireless (BT) Button:
• Press to select AC or DC on Low Z setting, AC or DC on voltage
setting, AC or DC on Amps setting.
• Press to activate Ohms, Continuity, Diode, Capacitance on
Ohms/Continuity/Diode/Capacitance setting;
T1, T2, T1 - T2 on temperature setting.
• Press and Hold to activate Wireless mode.
I. Range/Mode/
• Press to set manual range desired
• Press and hold Range/Mode/
J. Min/Max/Test Button:
• Press to capture Max reading
• Press again to capture Min reading
• Press again to capture Avg reading
• Press and hold return to Live readings
• Press and hold Min/Max/Test Button and Range/Mode/
activate Motor measurement test mode
B
CAT IV
600V
600A
A
V
30V
T
T
2
1
TEMP
Button:
kHz
Overview
M
N
O
P
Q
R
S
T
Button to activate Low filter mode
kHz
6
U
V
W
X
S/N
kHz
Button to
