The IRT807 is equipped with an AC "low-pass" filter. When measuring AC voltage press the Select Button to activate the "low
pass" filter function. The meter continues to measure in the selected AC mode, but the signal passes through the filter that blocks any
unwanted frequencies above 1kHz. The "low-pass" filter can improve measurement performance on composite sine waves that are
typically generated by frequency motor drives and inverters.
WARNING
• Use CATIII rated Test leads or higher.
• Do not attempt to measure more than 1000V AC.
• Keep hands below finger guards when measuring high voltage levels.
Features:
MIN/MAX
WARNING
• Use CATIII rated Test leads or higher.
• Do not attempt to measure more than 1000V DC.
• Keep hands below finger guards when measuring high voltage levels.
Features:
MIN/MAX
DC Volts
RANGE
4V
40V
400V
1000V
Accuracies apply to 100% of range
Input impedance 10MΩ (nominal), <100pF
Overload protection AC 1000V rms or DC
Voltage: with 1kHz "low-pass" filter <1000V
Test Voltage
LOCK
RANGE
A-HOLD
SELECT
F C
Voltage: <1000V DC
Apo
Apo
SELECT MIN/MAX
TEST
Temp
mV
V
kHz
V
OFF
Test Voltage
LOCK
RANGE
A-HOLD
F C
RESOLUTION
0.001V
0.01V
0.1V
1V
PI/DAR
Hz
IRT807
IRT807
V
V
Test Voltage LOCK
RANGE A-HOLD
F C
PI/DAR
Hz
ZERO
mA
SMOOTH
50V
1000V
10
ACCURACY
±(0.2% +3 dgts)
±(0.3% +6 dgts)
