SELECT
TEST
• Short the ends of the test leads together, press the SELECT button and wait until ZERO appears. The meter measures the
test leads resistance, stores the data/results in memory and subtracts it from the reading. The test lead resistance is saved
even after the meter is powered off. If the Probe resistance is >2Ω, the resistance will not be saved.
• Connect the test leads to the circuit to be tested. The tester will automatically detect if the circuit is energized.
• The display will show "----" until a valid resistance reading is detected.
• The High Voltage symbol will display if greater than 2V AC or DC is present. If the meter "chirps"when you press the
TEST button, test is corrupted due to voltage being present.
• Press and hold the TEST button on the Meter or Remote Probe to start test. Test stops when the button is released.
Features:
TEST
NOTE: When the resistance is higher than the maximum display range the tester displays the > symbol and the maximum
resistance for the range.
WARNING
NEVER test resistance on a live circuit. (Overload Protection: AC 2V rms or DC)
RANGE
20.00Ω
200.0Ω
2000Ω
20.00kΩ
1. Accuracies apply from 0 to 100% of range
2. Open Circuit Test Voltage: > 4.0V, < 8V
3. Short Circuit Current: > 200.0 mA
Earth-Bond Resistance <20kΩ
IRT 803
IRT803
V
Apo
Apo
SELECT
TEST
HOLD
1000V
ZERO
500V
250V
V
100V
OFF
ZERO
V
INSULATION
COM
CAT IV 600V
FUSED
CAT III 1000V
600V
SELECT
RESOLUTION
0.01Ω
0.1Ω
1Ω
0.01kΩ
• Default =
• Press x1 =
ACCURACY
±(1.5% +3)
8
