CAHORS
CS 60022 - 46003 Cahors cedex 9 - France
Tél. +33 (0)5 65 35 82 20 Fax + 33 (0)5 65 35 82 52
www.groupe-cahors.com
Switch Operation
The Autonomous / Cascadable button
allows the following actions:
- Autonomous mode to activate when
you have a single switch. It is to be
activated also on the last switch of a
column
The LED lights up when cascading
mode is enabled.
The Multiswitch can be powered by either an
external 12V-3A power supply or satellite
trunks.
The led "ALIM PSU" means that the
multiswitch is correctly powered.
Led of presence of the remote-feeding
12V antenna.
The Terrestrial input has an automatic remote
power supply to supply a mast pre-amplifier or
an active TNT antenna at 12V.
The LED must be illuminated: This means
normal operation of the multiswitch.
If LED off: There is a short circuit on the
Terrestrial input.
Note: Possibility to activate ACTIVE or PASSIVE
mode (switch on the side)
