Universal Series
MODEL
OD-9005PB | OD-1109PB | OD-1209PB | OD-1505PB
WIRING
WIRING
Run 120 V AC house wiring to the location of the fan. Use only UL- approved connectors (not included) to attach the house wiring to the wiring
plate. Refer to the wiring diagram, and connect the wires as shown.
ON/OFF
SWITCH
BLK
WHT
LINE
GRD
IN
SWITCH BOX
INSTALL GRILLE
Install ceiling material to complete the ceiling construction. Then,
cut around the fan housing.
To attach the grille assembly to the fan housing. Pinch the grille
springs on the sides of the grille assembly, and position the grille
into the housing with the grille springs in the appropriate slots.
Push the grille assembly towards the ceiling to secure.
SERVICE PARTS
PART
1
Grille Assembly (includes part 2)
2
Grille Spring
3a
Blower
4a
Blower Wheel
5a
Motor Plate
6a
Motor
3b
Blower
4b
Blower Wheel
5b
Motor Plate
6b
Motor
Hanger Bar Kit
7
Wire Panel / Harness Assemblye
8
Housing
9
10
Damper / Duct Connector
11
Wiring plate
a
Screw
b
Screw
c
Screw
d
Screw
* Blower Assembly includes part 3, 4, 5, 6, b, c
Ensure that the fan is switched off from the supply
WARNING:
mains before replacing.
