Picture-in-picture
Screen
Color palette
Diopter adjustment
Battery type
Charging
External power
Working time
Weight (with batteries)
Dimensions
IP rating
Working temperature
Storage temperature
11.
Cautions for use
− The VIS1055 thermal vision monocular has an uncooled microbolometer detector that uses a highly
sensitive thermal sensor. Never directly aim the lens at a strong source of radiation (such as the sun,
a laser beam, reflective surface, etc.) regardless of whether the product is switched on or off. This
would cause permanent damage to the monocular.
− Before first use, check the initial battery charge. If necessary, charge it for three hours before use.
When charging, do not expose to a temperature higher than 40°C.
− Keep the product out of reach of children.
12.
Maintenance
Lens
− Do not wipe the lens to remove loose dust or debris; instead, gently blow any impurity away or use
a soft lens brush.
− Fingerprints may affect the lens surface after some time. The easiest way to cleanse the lens is to
breathe on the lens surface, then gently wipe it using a lint-free optics-cleaning cloth.
− Use of a coarse cloth or unnecessary rubbing may scratch the lens surface and eventually cause
permanent damage.
− Do not use a velvet cloth or ordinary tissue, as it may scratch the lens surface.
− A cloth that has been used to clean the body of the product should not be used on the lens surface.
− For a more thorough cleaning, camera lens cleaning wipes may be used.
Main body
− Clean the body surface with a soft clean cloth. Do not use benzene, thinner, or any other cleaners
containing organic solvents.
Storage
− Water condensation or mold may occur on the lens surface due to high humidity. Avoid this by storing
the monocular in a cool, dry place. After use on a rainy day or at night, allow the product to dry
completely at room temperature before storing it in a cool, dry place.
VIS1055 - Indice B – Déc 2023
Yes
LCD screen 800*600
Iron hot, Red hot, Forest, White hote, Black hot
Yes
Li-ion, rechargeable
Supports USB charging and power bank
DC5V/2A (C-type)
5 continuous hours
331 g / 0.7 lbs
60*62*185 mm
IP66
-20°C - +50°C
-40°C - +60°C
14/16
