PoolDose | pH · ORP · Chlorine
12. ALARMS
Alarm
Level
*only active measures
Out of Range measure
OFA First Alarm
(time >70%)
OFA Second Alarm
Flow Rate
Calibration Function
System Error
1
Alarm measure (* )
1
(* Measure Alarm Ranges)
n
1 Temp. Measure min
2 Temp. Measure Max
3 pH Measure min
4 pH Measure Max
5 ORP Measure min
6 ORP Measure Max
7 CL Measure min
8 CL Measure Max
0000138994
Display
(time 100%)
Item
Actions to do
- Push
- Restore Product tank
- Replace or check the measure probe
- Push
- Restore measure
- Press
press
- Press
press
- Restore Flow Rate
- Restore Probe or Buffer solution and repeat
calibration procedure
- Press
- Broken Unit
- Adjust the chemical concentration
+ 10°C
+ 38°C
6 pH
8 pH
+ 600 mV
+ 800 mV
0,50 ppm
2 ppm
rev. 3.0 EN
to open Alarm Relay
to open Alarm Relay
for 3 seconds to reset or
for 5 seconds to reset
for 3 seconds to reset or
for 5 seconds to reset
to restore Default parameter
Limits
15
