Mediclinics M09ACS-I Manuel D'installation Et D'utilisation page 18

BASIC EXPLODED VIEW
Steel casing painted white
Steel casing painted black
Stainless steel casing with a polished finish
Stainless steel casing with a satin finish
Motor assembly
Electronic circuit
Heating element
Air filter
COMPONENT NUMBER
1
1
1
1
2
3
4
5
17
CODE
RC9224008SMD
RC9213008NEGRO
RC9213008SMD
RC9212008SMD
RC9111003SMD
RC9121011SMD
RC9141009SMD
RC9452009SMD
