Function and device overview
Using the device for any purpose
other than that described in this
operating manual does not fall
within the scope of intended use
and will invalidate any warranty or
liability.
4 Function and device
overview
The Homematic IP Radiator Ther-
mostat enables you to regulate the
room temperature in your smart home
based on the time of day using the
Homematic IP smartphone app and
to adjust the temperature to your re-
quirements. Customised temperature
schedules are easy to create using an
app – with up to 3 adjustable heating
schedules and 13 changes a day. Alter-
natively, you can set the temperature
directly on the device fully intuitively.
With the additional boost function,
cool rooms can be heated within short
by opening the heating valve. The ro-
tatable display and the contemporary
housing design mean that the radia-
tor thermostat fits perfectly into your
home environment. Any open win-
dows and doors are detected via an
open-window-detection function or
even more precisely in combination
with a Homematic IP Door / Window
Contact. Heating temperatures are
automatically lowered so that no en-
ergy is wasted. Once the windows are
closed, the temperature set for your
comfort will be reached again straight
away.
The radiator thermostat fits to all com-
mon radiator valves and is easy to
mount - without having to drain any
water or intervene in the heating sys-
tem.
Device overview:
(A) Metal nut
(B) Display
(C) Battery compartment (cover)
(D) System button (pairing button,
boost button and LED)
(E) Temperature adjustment via gentle
turning (clockwise or anticlockwise)
Display overview:
MANU
MANU
BOOST
BOOST
MANU
C
BOOST
MANU
C
C
BOOST
MANU
BOOST
C
C
MANU
BOOST
MANU
BOOST
C
Figure 1
Valve information:
Adjustment run
Valve information:
Initialisation
Setpoint temperature
Open window symbol
Batteries (almost) empty
Boost function
Manual mode
C
C
MANU
BOOST
B
D
E
C
