7. Screen
1- Down (-)
2- Up (+)
3- Menu
4- Camera selection (CAM1/CAM2)
5- Mode
6- ON / OFF
7- Power indicator
8. Wiring diagram
Screen
1 2
3
9. Warranty
The warranty applies to faults occurring during normal working conditions.
The warranty will become void when the device is damaged by improper use or care.
1
2
4 5 6
1 2
FUNCTION
ACTION
ON / OFF
POWER
Camera selection
CAM
Screen mode
MODE
Volume
x1 MENU
x1 (+)
Brightness
x2 MENU
x1 MENU
x1 (+)
x1 MENU
x1 (-)
Contrast
x1 MENU
x1 MENU
x1 (+)
x1 MENU
x2 (-)
Color
x1 MENU
x1 MENU
x1 (+)
x1 MENU
x2 (-)
Language
x1 MENU
x1 MENU
x2 (-)
x1 MENU
Mirror effect
x1 MENU
Mode
x6(-)
3
4
5
6
7
3
4 5 6
ADJUSTMENT
+ and -
+ and -
MENU to confirm
+ and -
MENU to confirm
+ and -
MENU to confirm
+ and -
MENU to confirm
Select the camera by
pressing on + or -
MENU to switch from ON
to OFF
MENU to switch from ON
to OFF
( OFF position is
recomended)
5
1- CAM 1
2- CAM 2 (Option)
3- 3A Fuse
4- Connect to + reverse bulb terminal
20m
(Green)
cable
5- Ground (Black)
6- +12V or +24V (Red)
When this product
has reached the end
of its useful life
dispose of it in a
disposal centre or at
your community
waste facility.
Do not dispose of
this product in your
normal domestic
waste as it must be
recycled in
accordance with
European Directive
2002/96/EC.
