The following requirements must be observed for the correct installation of the device:
• The device must only be installed by qualified personnel in accordance with national installation regulations. The controller is not
equipped with a mechanical circuit breaker and therefore does not provide galvanic isolation. To comply with safety regulations, the
module must be connected to an electrical line protected upstream by a C-curve 10A circuit breaker.
• The device must be installed respecting the direction indicated in the illustrations in this document.
• Connect the device in combination with a fuse holder with a high breaking capacity quick fuse type T1, 6AH/250V as shown in the
diagrams.
• It is necessary to comply with the maximum resistive load indicated in the load table.
• It is not recommended to install two dimmers in the same box.
• Do not connect several dimmers in series with each other.
• If electronic transformers for lamps are used, the transformer must support dimming.
Power supply: ..........................................................................................................................................................................................230V~
Frequency: .................................................................................................................................................................................................50Hz
Power on resistive load: .................................................................................................................................................................Max. 200W
Dissipated power: ....................................................................................................................................................................................... 2W
Working temperature range: ..............................................................................................................................................................0 ÷ 35 °C
Relative humidity: ................................................................................................................................................................................ 0 - 90%
Degrees of protection: ...............................................................................................................................................................................IP20
Dimensions of button (W x H): ................................................................................................................................................. 22,5 x 44,1 mm
Dimensions of module (L x H x D): ................................................................................................................................... 22,5 x 50 x 46,8 mm
Specific reference standards: .....................................................................................................................................................EN 60669-2-1
6
Load table
Controllable load
Incandescent lamps
Electronic transformers for 12 V
Ferromagnetic transformers for 12 V
lamps
LED lamps 230V~
Dimmable fluorescent lamps 230V~
Electronic transformers for LED lamps 12V
Ferromagnetic transformers for LED lamps 12V
LED Acrich - Acrich 2 module
Installation notes
Technical specifications
Power
4 ÷ 200 W
incandescent lamps 4 ÷ 200 W
incandescent
4 ÷ 100 W
4 ÷ 100 W
4 ÷ 100 W
4 ÷ 100 W
4 ÷ 100 W
4 ÷ 100 W
MAX
lamps
-
-
-
5
5
5
5
5
