Réchauffement Électrique / Electric heating
Résistances électriques de chauffe (optionnel)/ Electric heating resistances (optional)
Modèles « M2 »:
« RA »
« RB »
Si le câble d'alimentation est endommagé, il doit être remplacé par le
fabricant, par son service après-vente ou par du personnel qualifié similaire
dans le but d'éviter le danger.
Des moyens de déconnexion doivent être incorporés à l'installation fixe
en accord avec les règlementations de l'installation.
Pour le montage et le raccordement électrique de la résistance et les
panneaux de contrôle se référer aux instructions incluses dans chaque
kit de montage.
RÉSISTANCES ÉLECTRIQUES DE CHAUFFE / ELECTRIC HEATING RESISTANCES
Modèles
Puissance
Models
Power
(KW)
OPTIONS D’INSTALLATION / INSTALLATION OPTIONS
Modèles / Models
CV300M2
RA3/2-25
X
RA3/2-50
RB-50
RB-75
Boîtier de contrôle type TS / Control panel TS-type
Tension
Voltage
(V)
CV400M2
CV500M2
X
X
X
X
- Témoins de signalisation/ Pilot lights
Teº - Thermomètre / Thermometer
TRº - Thermostat de réglage / Regulating thermostat
The control panel TS-type is suitable for installation in wich the
calorifier controls the production of D.H.W. either by a primary
circuit of heating (boiler), (
The control panel ST has a thermometer and a regulating
thermostat.
« M2 » Models: Supplied with an TS-type panel (with a thermometer and regulating
thermostat). When installing electrical heaters the panel supplied with the tank must
be replaced by a TD-type or TPA-type.
The electrical resistances are provided in separate packages (see table available
powers and possibilities of application).
The electric resistance type « RA » are immersion heaters Incoloy 825 material, with
threaded connection 1-1/2 "Male.
The electric resistance type « RB » are immersion heaters Incoloy 825 material for
the installation flange at the hole side of the tank.
The direct connection with the control panel type "TD" is valid for resistances up to
2.5 kW. For higher powers, control over the resistance will be by means of an external
power contactor.
The connection to the control panel type "TPA" will be made through an external
contactor, regardless of the installed power
If power cable damaged, it must be replaced by the manufacturer or
its official technical service, or by similarly qualified personnel to
avoid any possible danger.
Unplugging safe mechanisms should be in place on the installation
according to the intallation directives.
For mounting and electrical connection of resistance and control panels
refer to the instruccions included in each kit assembly.
Longueur
Length
(mm.)
Trappe de visite DN 90 / Lower hole inspection ND 90
Trappe de visite DN 90 / Lower hole inspection ND 90
CV800M2
CV1000M2
X
X
X
X
X
X
X
X
TR°
position).
Installation
CV800M2B
CV1000M2B
X
X
X
X
