General system information
4
General system information
This device is part of the Homematic IP smart home system and works with
the Homematic IP protocol. All devices in the Homematic IP system can be
configured easily and individually with the CCU3 user interface or flexibly
with the smartphone app in connection with the Homematic IP cloud. The
functions provided by the system in combination with other components
are described in the Homematic IP Wired User Guide, available for down-
load. All current technical documents and updates are provided at www.
homematic-ip.com.
5
Start-up
5.1
Installation instructions
Since the bus is powered by the Homematic IP Wired Access Point
(HmIPW-DRAP), you must first set-up a Homematic IP Wired Access
Point (HmIPW-DRAP) to enable power supply for the device.
Before installation, please note the device number (SGTIN) labelled
on the device as well as the exact application purpose in order to
facilitate later allocation. You can also find the device number on the
QR code sticker supplied.
Installation may only take place in normal commercial switch boxes
(device boxes) in accordance with DIN 49073-1.
Please note the insulation stripping length of the conductor to be
connected, indicated on the device.
Please observe the hazard information in section „2 Gefahrenhinwei-
se" auf Seite 27 during installation.
Please note! Only to be installed by persons with the relevant elec-
tro-technical knowledge and experience!*
Incorrect installation can endanger
•
your own life,
•
and the lives of other users of the electrical system.
30
Incorrect installation also means that you are running the risk of serious
damage to property, e.g. from fire. You risk personal liability for personal
injury and property damage.
Consult an electrician!
*Specialist knowledge required for installation:
The following specialist knowledge is particularly important during ins-
tallation:
•
The "5 safety rules" to be used: disconnect from mains; safegu-
ard from switching on again; check that no voltage is present in
system; earth and short circuit; cover or cordon off neighbouring
live parts;
•
Select suitable tool, measuring equipment and, if necessary, per-
sonal safety equipment;
•
Evaluation of measuring results;
•
Selection of electrical installation material for safeguarding shut-
off conditions;
•
IP protection types;
•
Installation of electrical installation material;
•
Type of supply network (TN system, IT system, TT system) and
the resulting connecting conditions (classical zero balancing,
protective earthing, required additional measures etc.).
Permitted cable cross sections for connecting to the device are:
Rigid cable: 0.12-0.50 mm
For reasons of electrical safety, only the following cables may be used
for connecting to the Homematic IP Wired bus:
• Telephone cable J-Y(ST)Y with 2 x 2 x 0.8
(= 0.5 mm²) or 4 x 2 x 0.8 (= 0.5 mm²),
shielded, TP
•
Ethernet installation cable S/FUTP, Type Cat5e or higher with 2 x
2 x AWG22 (= 0.34 mm²) or
4 x 2 x AWG22 (= 0.34 mm²), shielded, TP
Start-up
2
31
