FILTER INSTALLATION PROCEDURE
1
4
Secure filter into place by moving filter clamp lever
back into the locked position until a click is heard.
2
Remove new filter from protective bag and
properly dispose of bag.
Holding the filter by the strap, align support cleat
with slot.
5
Close door until a click is heard. After closing door,
press door closed on corners and directly beneath latch
to ensure magnets and latch are fully secured.
3
Gently push in filter until a click is heard.
NOTE: if top and bottom supports are not properly
aligned, the filter will not sit properly and can
damage the unit.
