KNOWING YOUR TOWER FAN
In the Box
Check if all accessories are included. Contact us if there is any missing part.
Control Panel
LED Display
Air Outlet
Power Cord
Fan Base
Lock Nut
FRONT
Carry Handle /
Remote Holder
Air Inlet
REAR
Remote Control
(with CR2025 Battery)
3
Setting Up
Make sure that fan base is properly installed before plugging into an
electrical outlet.
1.
2
1
Unscrew Lock Nut
Unscrew the lock nut anticlockwise and
set aside.
3.
2
3
4
Install Fan Base
Pass the power cord across the fan base and lock nut.
1
Attach the assembled base to the body.
2
3 Tighten the lock nut clockwise.
Snap the power cord into the slot.
4
2.
Prepare Fan Base
Stagger the front and real bases slightly,
align pegs with slots and snap into place.
1
4
