CANGAROO GENTLE TOUCH DUO Notice D'utilisation page 14

•Charging time: 180 min
•Massage mode levels: 10 levels
•Suction mode levels: 15 levels
•Suction power range: 10-45 kP
•Baby bottle capacity: 130 ml
•Bottle material: PP
•Method of control: buttons
• Display: LCD
1.Before first time use charge the battery completely.
2.The breast pump is with a built-in battery 3.7V/ 1300 mAh.
3.Power connection:
•Plug the power adapter cable into the charging socket on the pump base.
•Plug the power adapter into an electrical outlet.
•Do not use the breast pump during charging, as its battery will be damaged.
4. Use only the charger provided with the breast pump. Do not use chargers from other products.
5. Charge the battery on time. Charge as soon as the battery indicator is with 1 bar or the indicator starts flashing.
6. During charging, the battery indicator will blink. Once the battery is fully charged, the indicator will stop flashing.
7. If you will not use the product for a long time, charge the battery completely before storing it. Then charge the battery
at least once a month to prolong its life.
8. If the battery is damaged or cannot be charged anymore, do not try to open the product by yourselves. For
consultation and repair contact the shop from where you bought the product or the importer/ distributor.
9. The battery is recyclable. If the product is damaged and cannot be used any longer, take it to an official collection point
for electronic products' waste, batteries, chargers. DO NOT throw the product away with the household waste. Follow
your country's rules for the separate collection of electrical and electronic products and rechargeable batteries. Dispose
of waste of this type only at the designated places. This will be important and significant contribution for the
environmental protection and the reduction of the harmful effects of the substances contained in batteries and electronic
components on the environment and human health.
ATTENTION! NEVER STERILIZE OR IMMEDIATE THE PUMP MECHANISM AND TUBE CONNECTING IT TO THE PUMP BODY
- PART 5; See Figure AD.
1. Step 1: Place the silicone valve (8) at the lower end of the pump body. Make sure that it is properly fixed around the
ends of the pump body opening intended for it. Important! If the valve is loose or not installed correctly, it will not be
possible to create a sufficient vacuum !.
2. Step 2: Fix the feeding bottle (10) to the pump body (6) by turning the bottle gently clockwise so that the thread of the
bottle coincides exactly with the thread of the pump body
3. Step 3: Place the piston (4) in the upper part of the pump body. Make sure that it is properly fixed around the ends of
the pump body opening intended for it.
4. Step 4: Put the protective cover (1) on the upper side of the pump body. Press and turn clockwise to fit in the correct
position.
5. Step 5: With clean hands, insert the silicone nozzle (2) into the pump body (6). As you need to make sure it is placed
tightly. Tip: If you are not going to use the breast pump, fit the protective cover (1).
6. Step 6: Attach the tubes (5) of the two pump bodies (6) to the connecting element (13). Then insert the tubes to the
pump bodies. Attach the third end of the connecting element and the third tube. Then attach this tube to the pumping
mechanism. So you can now use the breast pump.
Follow the attached product assembly schedules to ensure proper assembly.
Using the pump - See Figure UD.
1. Wash your hands thoroughly and make sure your breasts are clean. Express some milk to check that your milk ducts are
not blocked. The pump must be sterile and assembled.
2. Sit down and relax in a comfortable chair, leaning forward slightly (Use a soft and comfortable pillow as a backrest).
3.Put the pump on your breast and start the pump motor.
IV. CHARGING THE ELECTRIC MOTOR OF THE PUMP
V. ASSEMBLY OF THE ELECTRIC BREAST PUMP
VI. USE
