Loosen the clamping screw in clockwise direction and remove it together with the outer
flange and saw blade (2). Do not remove the inner flange from the spindle
▪
Place a new saw blade on the spindle and make sure that the bore of the saw blade
properly fits the inner flange . Ensure that the rotational direction indicated on the saw
blade is the same as the one shown on the upper fixed blade guard.
▪
Secure the saw blade (2) with the outer flange and clamping screw. Tighten the clamping
screw in anti-clockwise direction with the provided tool.
▪
Turn the saw blade by hand to test if it is rotating smoothly. It should not flutter.
▪
Secure the guard mounting plate and lower retractable blade guard (1) in reverse order as
described above.
When replacing the saw blade, you can tighten the slide bar with the
locking knob (21).
10 CLEANING AND MAINTENANCE
Before performing any work on the equipment, pull the power plug.
10.1 Cleaning
▪
Regularly clean the machine housing with a soft cloth, preferably after each use.
▪
If the dirt does not come off use a soft cloth moistened with soapy water.
▪
Never use solvents such as petrol, alcohol, ammonia water, etc. These solvents may
damage the plastic parts.
Make sure no water can reach the inside of the power tool!
10.2 Connecting cable
If the connecting cable (or mains plug) is damaged, it must be replaced. Replacement of the
connecting cable should only be carried out by a qualified specialist (qualified electrician).
11 TECHNICAL DATA
Nominal Voltage
Power rating
No load speed
Protection class
Blade size
12 CUTTING CAPACITY
Worktable tilting
angle
90°
45°
90°
45°
13 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
Acoustic power level LwA
Copyright © 2022 VARO
POWX075710S
Head tilting angle
90°
90°
45°
45°
P a g e
220-240 V ~ 50 Hz
1600 W (S6 25%)
5000 min-1
II
210 mm x 30 mm x 2.6 mm
Height x width (mm)
70 x 305 mm
70 x 210 mm
35 x 305 mm
35 x 210 mm
97 dB(A)
108 dB(A)
| 10
