EN /
I Charging your controller
The NACON GC-200WLRGB wireless controller is equipped with an internal 700mAh battery. To
charge this battery use the supplied Micro-USB cable and connect it to the socket on the top
of the GC-200WLRGB. Then plug it into one of your free USB ports on your PC. The 4 LEDs will
light up to indicate that the charging process has started and will also show the charging level
of the battery.
Remark: Please note that the controller cannot be used during the charging process.
I First-time connection with the PC
1. Turn on the controller by pressing the Home button for about 3 seconds. If it does not turn on,
make sure the controller battery is charged. (cf. Charging your controller).
2. Connect the wireless receiver of the GC-200WLRGB to one of the USB ports on your PC.
When your PC is on, Windows® detects a new device and automatically installs the appropriate
drivers. The process is indicated by an icon in the task bar.
3. After a few seconds, Windows® tells you that your controller is ready to use.
I Dongle compartment
When not in use, the dongle of your NACON GC-200WLRGB wireless controller can be stored in
the socket on the bottom of the controller to prevent it from loss.
Remark: The dongle compartment is for storage only and does not have any electronic function.
I D/X switch
There are different ways for modern computer games to communicate with your controller and
vice versa. Your GC-200WLRGB supports the two most commonly used ones: Direct Input 8 and
X-Input.
Sometimes a game only supports one of these two protocols. Since both can´t be run
simultaneously, your GC-200WLRGB features the D/X switch (10) to select one of these two
protocols, to make sure it works with all games.
Remark: After changing the protocol, the controller needs some short time to switch.
I Backlighting
On the back of your controller, you'll find a button to scroll through the different effects preset
in the controller.
Several effects are available: Prism, constant light, pulsing light or off.
