Autofocus
Autofocus
* Precautions:
01. When using chuck, roller, or engraving/cutting irregular
objects, like pebbles, soft materials such as office paper, kraft
paper, cashmere cloth, denim, etc, it is recommended to use a
fixed focus block to focus manually;
02. If there is a prompt of exceeding the maximum range, it is
necessary to raise the engraved object to ensure that the laser
module can touch the object within the effective stroke.
03. Keep a distance of at least 5mm between the laser slider and
the base; at the same time, make the laser be in natural contact
with the object, tighten the fixing screws to ensure the smooth
operation of autofocus.
Fixed focus method
5mm
Wrong
Correct
( A ) How to set "Autofocus" function in LightBurn:
01. Find "Window" in the top navigation bar, and enable "Console"
function in the drop-down menu
02. Select any custom button, right click mouse to pop up the
button setting page, enter the name of the button in "Button Label",
enter [ESP500] under "Macro contents"
