EN
Operating Headphones
Control Pad
POWER ON:
POWER OFF:
CONNECTING MODE:
PHONE Receive call/hang up: Press once
MUSIC Play/Pause:
PREVIOUS SONG:
QUIETER:
NEXT SONG:
LOUDER:
Cleaning and Storage
■
Never immerse the headphones in water or other liquids!
■
Under no circumstances should you use scratching, abra-
sive or aggressive cleaning products for cleaning.
•
Just wipe the headphones with a damp cloth.
•
To wash the hat/headband, remove the headphones and follow
the care instructions on the label.
18
Hold down for around 3 sec.
Hold down for around 3 sec.
Hold down for around 5 sec.
Press once
Press once
Hold down for a long time
Press once
Hold down for a long time
Replacing Ear Cushions
If the ear cushions are damaged or worn, they must be replaced.
Remove the old ear cushions from the headphones.
1
Peel the new ear cushions from the foil and stick them on the
2
headphones.
Technical Data
Headphone model: SF543/BTS
Sensitivity:
-35 dB (microphone);
120 +/- 3 dB (headphones)
Frequency range:
20 Hz – 20 kHz
Max. input power:
0.5 W
Impedance:
16 Ω
Bluetooth
version:
Vimicro 4.1
®
Bluetooth
range:
10 metres
®
Power supply:
3.7 V rechargeable battery (lithium polymer)
Battery lifetime:
approx. 500 charge cycles
Battery capacity:
180 mAH
Operating time:
approx. 8 hours of operation on full volume;
approx. 30 hours on standby (power on, but
without Bluetooth
DS Produkte GmbH hereby declares that the radio equipment type
"earebel" complies with Directive 2014/53/EU. The complete text
of the EU declaration of conformity is available at the following
internet address: www.service-shopping.de
Designated for sale in the Member States of the European Union:
AT
CZ
ES
GR
BE
DE
FI
HU
BG
DK
FR
HR
CY
EE
GB
IE
19
connection)
®
IT
MT
RO
LT
NL
SE
LU
PL
SI
LV
PT
SK
