PF Jones 29180537PF Instructions De Montage page 10

Scenic
15
Scenic
17
Grand Scenic
18
Scenic
19
/
87180976/16.01.2018
PF Jones Ltd, Nuttall street, Old Trafford, Manchester, M16 9JA, Tel- 0161 872 4755 email- info@pfjones.co.uk web- www.pfjones.co.uk
1
1 = BL/WT
2
2 = BK/YL
3
3 = GY/WT
4
4 = BR
1
1 = BK/YL
2
2 = GY/WT
3
3 = BL/WT
4
4 = BR
Grand Scenic
16
Close
secondary
lock!
1
2
3
4
Close
secondary
lock!
1
2
3
4
Grand Scenic
20
1 = YL/WT
2 = BK/YL
3 = GY/WT
4 = BR
1 = BK/YL
2 = GY/WT
3 = YL/WT
4 = BR
10/17
