OPERATING INSTRUCTIONS
MODEL: ET6207
LONG LEAD 4-RANGE VOLTAGE-
CONTINUITY TESTER
BEFORE USE:
READ ALL OPERATING INSTRUCTIONS BEFORE USE. Use extreme caution when
checking electrical circuits to avoid injury due to electrical shock. Sperry Instruments
assumes basic knowledge of electricity on the part of the user and is not responsible
for any injury or damages due to improper use of this tester.
OBSERVE and follow all standard industry safety rules and local electrical codes.
When necessary call a qualified electrician to troubleshoot and repair the defective
electrical circuit.
SPECIFICATIONS:
Operating Range: 80-480 VAC/DC, 60 Hz; CAT III 600V
Indicators: Visual Only
Operating Environment: 32° - 104° F (0 - 32° C)
Altitude up to 2000 meters. Indoor use.
Pollution degree 2. Accordance with IED-664.
Cleaning: Remove grease and grime with clean, dry cloth.
OPERATION:
To test for voltage insert test leads into outlet or carefully touch test leads to
electrical contacts or circuit to be tested. If voltage is present the neon indicators in
the correct range will glow. Use the highest illuminated range for the correct
voltage. The brightness of the bulbs will increase as the voltage increases.
To test for the live side of an electrical outlet insert one probe into the ground plug
of the outlet while inserting the other probe in the alternate sides of the outlet. The
neon indicator(s) will glow when the probe makes contact with the live side.
SINGLE HAND OPERATION:
Sperry's unique design allows for convenient single hand testing of outlets when
the probes are secured side-by-side on the tester housing. Just insert the probes
into the outlet and if voltage is present the neon indicator(s) will glow.
To test for continuity just place the probe tips on the circuit to be tested.
If continuity (continuous circuit with no breaks) is present the continuity indicator
LED will light.
Batteries: This tester requires two 1.5 Volt button cell batteries (LR44, SR44, A76,
G13, AG13, GP76A, 257, D357, V13GA) for the continuity function. To test if the
batteries are good and the continuity test function is operating properly touch the
two test leads together. If the continuity indicator does not light then replace the
batteries by removing the battery cover on the back of the tester.
CAUTION – REFER TO THIS MANUAL BEFORE USING
THIS TESTER.
Double Insulation: The tester is protected throughout by double insulation
or reinforced insulation.
Limited Lifetime Warranty limited solely to repair or replacement;
no warranty of merchantability or fitness for a particular purpose. Product is
warrantied to be free of defects in materials and workmanship for the normal
life of the product. In no event shall Sperry Instruments be liable for incidental
or consequential damage.
2150 Joshua's Path, Suite 302, Hauppauge, NY 11788
P.O. Box 9300, Smithtown, NY 11787-7929
1-888-952-1126 • 1-631-952-1126 • Fax: 1-631-434-3128
80% RH max., 50% RH above 30° C
Form # 379 4/06
©2006 SPERRY INSTRUMENTS, INC.
